Din Rail Mountable Terminal Blocks (Live, Neutral, Earth)

A terminal block (also called as connection terminal or terminal connector) is a modular block with an insulated frame that secures two or more wires together. It consists of a clamping component and a conducting strip.

The insulating body of a terminal block houses a current carrying element (a metal strip or terminal bar). It also provides a base for clamping element. The body has a mounting arrangement so that the block can be easily mounted on a DIN rail.

Single level pass-through terminal blocks: Grey (Live), Blue (Neutral)

These are simply used to connect two wires together, i.e. wire-to-wire connection. These are also called as single feed terminal blocks. Single level terminal blocks are of the most simple type having one input contact and one output contact.

Ground terminal blocks - Green/Yellow

These blocks often look like a single level feed through terminals. The exception is that these blocks and the metal connection where the wire is terminated are grounded to the panel or DIN rail on which the block is mounted. (therefore making a Quick and easy connection to common Earth)

Product Information (live and neutral)

Dimensions
