Business Pro Dual 22kW Commercial EV Charger – Three-Phase
Couldn't load pickup availability
Pricing Information
All prices are shown ex VAT. VAT is calculated and added at checkout where applicable.
EU Deliveries
Shipments to the EU may be subject to local taxes, import duties, or customs fees, which are the responsibility of the recipient.
Up to 2 × 22kW from a single commercial unit — the Business Pro Dual 22kW delivers maximum throughput for high-demand locations where vehicles park for a few hours rather than overnight.
The Business Pro Dual 22kW is the higher-output version of the commercial dual charger, delivering up to 22kW to each of its two Type 2 sockets simultaneously. It is suited to commercial car parks, fleet depots, hotel facilities, and locations where vehicles dwell for shorter periods and faster charging represents a genuine advantage over lower-powered units.
Three-phase electricity supply is required at the installation site. All other specifications match the 7kW model: OCPP 1.6J compliance, MID-certified billing meter, RFID access control, dynamic and static load management, Ethernet and power daisy-chaining up to 100A, and optional payment terminals. Integrated RCBO and PEN fault protection simplifies installation. Mounted on the EV block 600 pedestal, sold separately.
UK-manufactured and backed by a 5-year hardware warranty and 10-year enclosure warranty.
Specifications
| Output | Up to 2 × 22kW (simultaneous) |
| Sockets | 2 × Type 2 |
| Supply | Three phase (required) |
| Protocol | OCPP 1.6J |
| Access control | RFID |
| Metering | MID-certified (±2%) |
| Connectivity | Ethernet (standard), Wi-Fi, Bluetooth |
| Payment | Optional payment terminal |
| Load management | Dynamic and static |
| Scalability | Ethernet + power daisy-chain (up to 100A) |
| Protection | Integrated RCBO, PEN fault protection, surge |
| IP rating | IP54 |
| Impact rating | IK08 |
| Back-office | Integrated software, mobile app, OTA updates, health monitoring |
| Mounting | Freestanding (EV block 600, sold separately) |
| Origin | UK manufactured |
| Hardware warranty | 5 years |
| Enclosure warranty | 10 years |
| Compliance | UK Smart Charge Point Regulations, UKCA, CE, BS 7671 |
Frequently Asked Questions
When should I choose 22kW over 7kW?
Choose 22kW if vehicles dwell for under 4 hours, or if your users drive EVs with 11kW or 22kW onboard chargers. For all-day parking (offices, rail stations), 7kW per socket is often sufficient and uses less supply capacity.
How much three-phase supply capacity do I need?
Each 22kW socket draws up to 32A per phase at maximum load. Dynamic load management reduces this in practice. For larger installations, contact Eco Harmony for a site survey and load calculation before ordering.
Is it suitable for public charging networks?
Yes. OCPP 1.6J compliance, optional payment terminals, MID metering, and back-office integration make it suitable for both public-facing networks and private commercial installations.
