By BG Electrical

BG 5 Module IP65 White Empty Metal Enclosure

£19.50 - £110.00
Regular price £19.50
Regular price £23.45 Sale price £19.50
-£3.95

BG 5 Module white empty metal enclosure with DIN rail, IP65 for Outdoor Application

The white metal enclosure is designed to be used to protect electrical components installed outdoors. It has a high degree of protection at IP65, making it applicable for outdoor mounting. The unit is supplied with internal terminal blocks for connection of neutral line and protective grounding wire.

It can house DIN rail mountable units up to 5 widths total. This could be used as part of a charge point installation or electrical work where a reliable metal IP65 Enclosure is required.

If using our EPC's a functional charge point could be assembled inside this enclosure. Some modules, such as our Tethered EPC are 2 Modules wide. An example of what modules would fit are below:

Key Features

  • Up to 5 modules mountable
  • White BG Box
  • IP65 Rated
  • RCBO Reset and Viewing Window
  • Ideal for a tethered charging solution
  • Suitable for use in Solar installations

Compatible with Tethered Cable Kit


Dimensions

  • 167.5mm x 234.5mm x 100mm

Electrical Properties

  • Electric ratings: up to 63A, 230V, AC50/60Hz;
  • No. of mounted units: 5;
  • Allowable temperature-rise of enclosure: 40k;
  • Protection degree: IP65;
  • Standard: IEC 60364/BS7671
  • 20mm knockouts on all sides drillable to 32mm

Manufacturer Part Number: CFE5W

Datasheet

Installation Manual

Safety
Always check with qualified installer for suitability and adherence of local wiring regulations.
